275nm 280nm 265nm Germicidal Deep UV UVC 3535 4040 LED 5-10MW 10-18MW for Water Air ...

We are committed to providing our customers with perfect experience through superb nichia nvsu233b, cob led lamp, red 2835 led and services and the integration of quality resources. We do our best to create fine services for our customers. We strengthen the construction of our workforce with quality improvement and ability cultivation as the core.

UVC LED Chip SMD 265nm 10mW

• Nitride Aluminum Ceramic Base

• Eutectic Bonding technology

• Wavelength from 265nm to 280nm

• Radiance Decay only 5% over 1000hrs working.

• True Radiance Power from 8mw to 12mw

• More energy efficient than254nm mercury lamps

• Low Voltage DC operated

• Instant light(less than 100ns)

Product Features

• Nitride Aluminum Ceramic Base

• Eutectic Bonding technology

• Wavelength from 265nm to 280nm

• Radiance Decay only 5% over 1000hrs working.

• True Radiance Power from 8mw to 12mw

• More energy efficient than254nm mercury lamps

• Low Voltage DC operated

• Instant light(less than 100ns)

Product Dimension

Product Specification

Absolute Maximum Ratings(At TA =25℃)

Electrical/Optical Characteristics--White (At TA=25°C)

Product Application

Packing Method

Normal packing Quantity: 1000pcs/reel in vacuum bag.

Shipping Method

Delivery time:

●Order Qty<500.000pcs, 3-7 workdays.

●Order Qty>500.000pcs, 7-12 workdays.

●Order Qty>2000.000pcs,12-20 workdays.

Production Flow

Q&A

How To Pick The Best UV Light For HVAC?

In my view as a licensed inspector, there are basically two different types of UV lights that you can install for your HVAC system: surface treatment and air treatment.

#1. Surface Treatment UV Lights

Surface UV lights are installed above or next to the evaporator coil of the interior air handler.

These UV lights are meant to kill and prevent microbial growth on the surface of the coil, the ductwork, and anything else the light can reach such as the drip pan or blower fan.

Surface UV lights are great at preventing the growth of so-called biofilms on the furnace surfaces especially the evaporator coil. Biofilms are basically a slimy film of microbes that live together as a single community. Biofilms can release hazardous mold spores into the air and can also seriously decrease the efficiency of the HVAC system.

#2. Air Treatment UV Lights

Air treatment UV lights are installed on the return side of the air handler which is basically the opposite of surface treatment UV lights. When it is installed on the return side, these UV lights kill microbes that are actually in the air, and not just on the surface.

Many of these air treatment UV lights come equipped with air flow sensors so that the light only turns on when the furnace is actually running --- significantly extending the longevity of the light bulb.

In addition, since the UV light is installed on the return side, it is less likely to damage some of the plastic components of the furnace such as the wiring and the drip pan.

Light Bulb Size

There are generally two types of UV light bulbs --- long and short.

If the unit you are buying has a longer bulb, it may be more difficult to install if your furnace is in a very small utility closet. However, with a longer bulb, there is more “surface area” so the light may shine along more areas increasing it’s effectiveness.

Sheet Metal Drill Bit

Another factor to consider is the equipment that comes with the purchase. Some UV light systems come with everything you need for the installation including the sheet metal drill bit that you will need to make holes in the ductwork.

Almost all UV air sanitizers will come with a few screws and a paper template in order to mount the system onto the duct.

Cord Length

Another thing to consider is the cord length. Most UV light systems come with a power cord that is 6′ to 8′ in length. If your utility closet doesn’t have a regular 3-pronged outlet, you may need to buy an extension cord that will go to the closest outlet.

And again, you can also wire the ultraviolet purifier into the air handler electrical system, and even wire it so it turns on only when the system is on. An electrician or contractor may be required for custom wiring.

Company Environment

Factory Environment

Guangmai (GM) Company have over 12 years experience of produce a full series of high quality LED for different application such as high lumen smd2835 led, SMD3535 LED, SMD3030 LED,SMD5050 LED,High power LED and COB LED from 5watt-100watt.

Since 2010, we are the top100 reliable LED enterprise in China and TOP10 LED company in Shenzhen. .
For more info about us, pls send us an inquiry or welcome to visit our Shenzhen headquarter and production base for business negotiation, Looking forward to work with you soon!

GMKJ SERVICE:

1. 7x24 hours stand-by service . fast feedback.

2. Free consult about light fixture design and circuit design.

3. Custom made CCT/RA/Voltage/Size Available

4. PCB design / LED smt service

5. Constant temperature/humidity warehouse Free stock service

6. Drop-shipping service to third party with neutral labels.

7. 3-5 Years long quality guarantee.

8. Offer professional suggest about material sourcing.

We are committed to innovative, environmentally friendly 275nm 280nm 265nm Germicidal Deep UV UVC 3535 4040 LED 5-10MW 10-18MW for Water Air ... that address environmental challenges and drive economic growth. We make use of our R&D facilities and marketing personnel in different regions to gain an in-depth understanding of our customers' engineering needs. While expanding the scale of production, we always believe in quality assurance.
