Far red led 730nm SMD 3030
●Made up by Original Sanan LED Die.
●Dimension (L x W x H) in mm:3.0x3.0mm
●High Radiant power up to 350mw each LED
●Viewing Angle (2θ1/2): Typical 120°
●Economy LEDs for LED plan Grow light.
●Low light attenuation less than 3% over 10000hrs.
●EN62471,LM80,Rohs Approved
Product Dimension
Product Specification
Absolute Maximum Ratings(At TA =25℃)
Parameter | Symbol | Rating | Unit |
DC Forward Current | IF | 350 | m A |
Peak pulse Current* | IFP | 700 | m A |
Power Dissipation | PD | 1 | W |
Reverse Voltage | VR | 5 | V |
Reverse Current | IR | 10 | μ A |
Operating Temperature Range | TOPR | -30 ~ +75 | °C |
Storage Temperature Range | TSTG | -40 ~ +85 | °C |
LED Junction Temperature | TJ | 120 | °C |
Electrical/Optical Characteristics--White (At TA=25°C)
Parameter | Symbol | Conditions | Min | Avg. | Max | Units |
Forward Voltage | VF | IF=350mA | 1.80 | -- | 2.40 | V |
Thermal Resistance Junction To Board | RΘJ-B | IF=350mA | -- | 8 | -- | °C/W |
Radiant Power | Φe | IF=350mA | 250 | 350 | mw | |
Peak wavelength | λp | IF=350mA | 730 | 740 | nm | |
Temperature Coefficient of Forward Voltage | ∆VF/∆T | IF=350mA | −− | -2 | −− | mV/°C |
Reverse Current | IR | VR=10V | −− | −− | 10 | μ A |
Viewing Angle [1] | 2Θ1/2 | IF=350mA | −− | 120 | −− | Deg |
Product Application
Deep red 730nm LED for Plan Grow light.
TheFar red led 730nm SMD 3030 is especially beneficial during bloom phase, promoting large bud growth and healthy flowers. 730nm is very close to the absorbance maxima of chlorophy a. Many LED grow lights are deficient in 730nm red. Use this light to enhance and correct your light spectrum.
Other SMD LED hot sale
2020GM PLANT GROW LIGHT SMD LED | ||||
ITEM | MODEL | (PPE) μmol/J | IF/VF(V) | chip size |
2835/3030/K2/3535 Pkant Grow light Single color LEDs | ||||
1 | 2835Blue 450nm 0.2W | 1.8-2.0 | 60mA/2.9-3.2 | Jucan 12*29 |
2 | 2835Red 620nm 0.2W | 1.4-1.8 | 60mA/2.0-2.4 | Sanan 12*12 |
3 | 2835Red 660nm 0.2W | 2.2-2.4 | 60mA/2.0-2.4 | Sanan 14*14 |
4 | 2835Red 740nm 0.2W | 50mW | 60mA/19.0-2.3 | Epileds 14*14 |
5 | 2835Blue 450nm 0.5W | 2.0-2.2 | 150mA/3.0-3.2 | epistar 17*34 |
6 | 2835Red 620nm 0.5W | 1.7-2.0 | 150mA/2.0-2.4 | Epileds 20*20 |
7 | 2835Red 660nm 0.5W | 2.1-2.3 | 150mA/1.9-2.3 | Epileds 20*20 |
8 | 2835Red 740nm 0.5W | 100mW | 150mA/2.0-2.2 | Sanan 20*20 |
9 | 2835Blue 450nm 1W | 2.0-2.3 | 350mA/2.8-3.0 | HUACAN 22*38*2 |
10 | 2835Red 620nm 1W | 2.0-2.3 | 350mA/2.0-2.4 | Epileds 42*42 |
11 | 2835Red 660nm 1W | 2.1-2.3 | 350mA/2.0-2.4 | Epileds 42*42 |
12 | 2835Red 740nm 1W | 300mW | 350mA/1.6-2.0 | Sanan 42*42 |
13 | High power LED Blue 450nm 1W | HIGH POWER LED AND SMD3535 LED PACKAGE Style also available for plant grow lights | ||
14 | High power LED Red 620nm 1W | |||
15 | High power LED Red 660nm 1W | |||
16 | High power LED Red 740nm 1W | |||
17 | EMC3030 Blue 450nm 1W | 1.7-2.2 | 350mA/2.9-3.2 | Epileds 45mil |
18 | EMC3030 Red 620nm 1W | 1.8-2.3 | 350mA/2.0-2.4 | Epileds 42*42 |
19 | EMC3030 Red 660nm 1W | 1.9-2.3 | 350mA/2.0-2.4 | Epileds 42*42 |
20 | EMC3030 Red 740nm 1W | 300mW | 350mA/1.6-2.0 | Sanan 42*42 |
25 | 2835 WHITE high PPE | 2.9-3.1 | 60mA/2.7-3.0 | Huacan 22*38*2 |
26 | 3030 WHITE High PPE | 2.8-3.0 | 60mA/2.7-3.0 | Hucan 22*38*2 |
27 | Full Spectrum 2835(RA95-98） | GS-3526W6-JC1734 | 0.2-0.3w | Jucan1734, cct6500k/4000k/3000k,23-25lm |
28 | Full Spectrum 2835(RA95-98） | GS-3526W6-JC1530 | 0.2-0.3w | Jucan1530， cct6500k/4000k/3000k,22-24lm |
29 | Full Spectrum 2835(RA95-98） | GS-3526W6-JC1229 | 0.2w | Jucan1229， cct6500k/4000k/3000k,21-23lm |
Shipping Method
Delivery time:
●Order Qty<10000pcs, 3-5 workdays.
●Order Qty>10000pcs, 7-12 workdays.
●Order Qty>50000pcs,12-20 workdays.
