UV LED 365nm 3535 SMD
●Use Original LG or Epileds chips
●Dimension (L x W x H):3.8X3.8X3.05mm
●High Radiance intensity for compact design
●Nitride Aluminum Ceramic base
●Viewing Angle (2θ1/2): Typical 60- 125°
●LM-80 , EN62471 , Rohs Certificate APPROVED
Product Application:
●Plant Grow Light
●Currency,Jewelry,Ore detection.
●Ink Curing, PCB exposure
●Mosquito trap lamp.
Product Dimension
Product Specification
Absolute Maximum Ratings(At TA =25℃)
Parameter | Symbol | Typical values | Unit |
DC Forward Current | IF | 1000 | m A |
Peak pulse Current* | IFP | 2000 | m A |
Power Dissipation | PD | 4 | W |
Reverse Voltage | VR | 5 | V |
Reverse Current | IR | 10 | μ A |
Operating Temperature Range | TOPR | -30 ~ +80 | °C |
Storage Temperature Range | TSTG | -40 ~ +85 | °C |
LED Junction Temperature | TJ | 120 | °C |
Electrical/Optical Characteristics--White (At TA=25°C)
Parameter | Symbol | Conditions | Min | Avg. | Max | Units |
Forward Voltage | VF | IF=1000mA | 3.60 | -- | 4.00 | V |
Thermal Resistance Junction To Board | RΘJ-B | IF=1000mA | -- | 8 | -- | °C/W |
Radiant Flux | Φe | IF=1000mA | 1000 | 1500 | mW | |
Peak wavelength | λp | IF=1000mA | 365 | 370 | nm | |
Temperature Coefficient of Forward Voltage | ∆VF/∆T | IF=1000mA | −− | -2 | −− | mV/°C |
Reverse Current | IR | VR=5V | −− | −− | 10 | μ A |
Viewing Angle [1] | 2Θ1/2 | IF=1000mA | −− | 60 | −− | Deg |
Shipping Method
Delivery time:
●Order Qty<10000pcs, 3-5 workdays.
●Order Qty>10000pcs, 7-12 workdays.
●Order Qty>50000pcs,12-20 workdays.
Production Flow:
