100w Flip chip COB LED cool white 6500k

Product Features:

Item Name: 100w Flip chip COB LED cool white 6500k

Model Number: GF-100WW6-4046

Input Current: 3000-3500mA

Power Consumption: 100W

Input Voltage: 30-34VDC

LED package type:20*20mm size

Chips brand: Sanan or Bridgelux

Brightness: 120-130LM/W

Color Temperature: 6000-6500k

4046 dim

10-100W FLIP CHIP COB LED Specs
Power	Current(mA)	Voltage(VDC)	Chips brand	Chip Size	Color Temperature(K)	Lumen(lm)
10W	300	28-34	Sanan	1530mil2	2600-7000	110-130lm/w
20W	600	28-34	Sanan	1530mil2	2600-7000	110-130lm/w
30W	900	28-34	Sanan	1530mil2	2600-7000	110-130lm/w
40W	1200	28-34	Sanan	1530mil2	2600-7000	110-130lm/w
50W	1500	28-34	Sanan	1530mil2	2600-7000	110-130lm/w
60W	1800	28-34	Sanan	1530mil2	2600-7000	110-130lm/w
70W	2100	28-34	Sanan	1530mil2	2600-7000	110-130lm/w
80W	2400	28-34	Sanan	1530mil2	2600-7000	110-130lm/w
90W	2700	28-34	Sanan	1530mil2	2600-7000	110-130lm/w
100W	3000	28-34	Sanan	1530mil2	2600-7000	110-130lm/w

Application

Industry Standard Size Chip-on-Board package provide utmost flexibility to both indoor and outdoor applications

Premium commercial lighting, Industrial lighting, residential lighting, special lighting (horticulture, studio lighting) etc

LEDs with Flip Chip Technology

Thanks to new technological innovations, we are now able to produce even more energy-efficient LEDs. The new flip chip technology lowers costs and energy consumption, and minimises our ecological footprint.

Greater efficiency equals less environmental impact

The latest version of the Ljusamallen lighting guide (2019) presented new guidelines for the lifespan and energy-efficiency of luminaires. A new requirement is that lighting planning in certain segments must be calculated using light levels beyond 100,000 hours. A high L-value for luminaires and little or no light depreciation may result in fewer luminaires being needed in a room. This, together with increased efficiency and minimal light depreciation, is something we can all benefit from, not least the environment.

High performance, low maintenance

LED luminaires are essentially maintenance-free, since the bulbs do not require replacing. They contain no moving or fragile parts, and – if properly designed – LED luminaires withstand vibrations and other disturbances in the room very well. In areas with a lot of movement, such as sports halls or industries where the luminaires are usually high up on the ceiling, little maintenance and high durability make daily operations easier. Another advantage of their durability is gained by facilities which operate around the clock. For hospitals and hotels, for example, downtime due to maintenance can be costly and difficult to plan for.

LEDs with Flip Chip Technology

In 2019, Fagerhult is launching new LEDs with flip chip technology. Flip chip technology is relatively new and involves mounting the chip upside down in the LED housing (in relation to so-called Epi-Up). The design of the chips improves heat dissipation, which will further reduce energy consumption with up to 20% less energy consumed compared to current LEDs. The LEDs also preserve the long luminaire lifespan of 100,000 hours without light depreciation. The new flip chip LEDs are being launched primarily for luminaires in segments where lighting is seldom replaced, positioned high up on ceilings, or in use around the clock.

Owing to the long lifespan of the luminaires and bulbs, as well as the low energy consumption, an investment into a Fagerhult luminaire with flip chip LEDs is an investment into the future. The high durability and low maintenance result in hassle-free lighting in the premises.
