Name: China GMKJ 5W 450nm 3535 Ceramic SMD High Power Royal Blue LED For Horticultural Lighting Manufacturers, Suppliers - Factory Direct Price - Guangmai Technology
Brand: GMKJ
SKU: 314100541

GMKJ 5W 450nm 3535 Ceramic SMD High Power Royal Blue LED For Horticultural Lighting

GMKJ 5W 450nm 3535 Ceramic SMD High Power Royal Blue LED is a high-performance light source for premium horticultural lighting, aquarium lighting and machine vision systems. Its 450nm wavelength delivers stable royal-blue output with precise spectral control and high optical intensity. Featuring a 3535 ceramic package, this 5W LED provides excellent heat dissipation and stable performance during continuous operation, while its compact form factor enables easy integration into various high-power lighting fixtures. It supports customized spectral recipes for horticultural lighting, meets the spectral requirements of high-end aquarium lighting, and provides stable illumination for machine vision inspection equipment. GMKJ supplies customized 450nm LED solutions for OEM manufacturers, supporting optical, electrical and packaging customization from prototype development to mass production.

GMKJ 5W 450nm 3535 Ceramic SMD High Power Royal Blue LED

450nm Royal Blue LED for Premium Horticultural Lighting

450nm Horticulture

450nm Royal Blue LED for High-End Aquarium Lighting

450nm Aquarium

450nm Blue LED for Machine Vision Inspection Lighting

450nm Machine Vision

LED Parameters & Wavelength Options

GMKJ 3535 Ceramic SMD High Power Blue LEDs are available across multiple wavelength options from 440nm to 490nm. Different wavelength selections can be used to achieve specific spectral requirements in premium horticultural lighting, aquarium lighting and machine vision systems.

Parameter	Specification
	3W 440-450nm LED
Product Code	GTY-3535B445-1CZ0-G1D5M
Peak Wavelength	440-450NM at 700mA 3V

	3W-10W 450-460nm LED
Product Code	GDY-3535B450-1CD0-S1E5M
Peak Wavelength	450-460NM at 1500mA 3V

	5W 460-470nm LED
Product Code	GDY-3535B460-1CC0-S1C8M
Peak Wavelength	460-470NM at 1500mA 3V

	5W 470-480nm LED
Product Code	GTY-3535B470-1CC0-S1C8M
Peak Wavelength	470-480NM at 1500mA 3V

	3W 480-490nm LED
Product Code	GTY-3535B480-1CZ0-G1D5M
Peak Wavelength	480-490NM at 700mA 3V

	3W 490-500nm LED
Product Code	GTY-3535G490-1CZ0-G1D5M
Peak Wavelength	490-500NM at 700mA 3V

Available Wavelength Range

440nm | 450nm | 460nm | 470nm | 480nm | 490nm

For detailed electrical and optical specifications, including forward voltage, operating current, radiant flux, viewing angle and wavelength tolerance, please contact GMKJ for the corresponding product datasheet and test data.

LED Product Images

5W 450nm 3535 Ceramic SMD Royal Blue LED

450nm

450nm LED

450nm Royal Blue LED Spectral Test Data

450nm test

Parameter	Symbol	Conditions	Min	Avg.	Max	Units
Forward Voltage	V_F	I_F=1500mA	2.70	--	3.10	V
Luminous Flux	Φv	I_F=1500mA	80		100	lm
Dominant wavelength	λd	I_F=1500mA	450		455	nm
Reverse Current	I_R	V_R=5V	−−	−−	10	μ A
Viewing Angle^[1]	2Θ_1/2	I_F=1500mA	−−	120	−−	Deg
Thermal Resistance Junction To Board	RΘ_J-B	I_F=1500mA	--	5	--	°C/

Custom 450nm LED Solutions for Your Lighting & Vision Project

For wavelength selection, application support, or sample requests related to high-power ceramic LEDs, please contact:

Jennin
GMKJ LED | High Power Ceramic LED Solutions

Email: gmkj06@gmleds.com
WhatsApp: +86-18878641376
