Ir Led 1w Ir 3535 3w Smd Leds 850nm 940nm

Guangmai Technology is professional in making the ir led 1w ir 3535 3w smd leds 850nm 940nm.

Features

Package ( L/W/H ) : 3.45×3.45×2.0mm

Lens: Water Clear

EIA STD Package

Meet ROHS, Green Product

Compatible With SMT Automatic Equipment



Order Code	Voltage (V)	Peak     Wavelength (nm)	Radiant   Power (mW)	Radiant Intensity (mw/sr)	Current (mA)	Half Width (nm)	Angle (0)	Power (W)
GM-35R45N450KN-D1	3.0-3.4	450-460	700-800	341	700	20	120	3W
GM-35G45P460KN-D1	3.0-3.4	460-470	400-500	281	700	22	120	3W
GM-35G45P480KN-D1	3.0-3.4	470-490	800-1000	262	700	26	120	3W
GM-35G45P500KN-D1	3.0-3.4	495-505	300-400	235	700	25	120	3W
GM-35G45P530KN-D1	3.0-3.4	530-540	300-400	236	700	30	120	3W
GM-35G45P545KN-D1	3.0-3.4	540-560	200-300	227	700	40	120	3W
GM-35F45N560KN-D1	3.0-3.4	555-575	80-100	300	700	40	120	3W
GM-35E42P590KN-D1	2.0-2.4	590-600	100-130	85	700	20	120	3W
GM-35G42N600KN-D1	2.0-2.4	600-610	250-350	187	700	15	120	3W
GM-35E42P630KN-D1	2.0-2.4	620-640	400-500	461	700	15	120	3W
GM-35E42N660KN-D1	2.0-2.4	655-665	600-700	794	700	17	120	3W
GM-35G42N680KN-D1	2.0-2.4	670-690	700-800	774	700	20	120	3W
GM-35R45N450KN-X1	3.0-3.4	450-460	700-800	341	700	20	60	3W
GM-35G45P460KN-X1	3.0-3.4	460-470	400-500	281	700	22	60	3W
GM-35G45P480KN-X1	3.0-3.4	470-490	800-1000	262	700	26	60	3W
GM-35G45P500KN-X1	3.0-3.4	495-505	300-400	235	700	25	60	3W
GM-35R45N520KN-X1	3.0-3.4	520-530	250-350	227	700	30	60	3W
GM-35G45P530KN-X1	3.0-3.4	530-540	300-400	236	700	30	60	3W
GM-35G45P545KN-X1	3.0-3.4	540-560	200-300	227	700	40	60	3W
GM-35F45N560KN-X1	3.0-3.4	555-575	80-100	300	700	40	60	3W
GM-35E42P590KN-X1	2.0-2.4	590-600	100-130	85	700	20	60	3W
GM-35G42N600KN-X1	2.0-2.4	600-610	250-350	187	700	15	60	3W
GM-35E42P630KN-X1	2.0-2.4	620-640	400-500	461	700	15	60	3W
GM-35E42N660KN-X1	2.0-2.4	655-665	600-700	794	700	17	60	3W
GM-35G42N680KN-X1	2.0-2.4	670-690	700-800	774	700	20	60	3W
GM-35G45P560KN-S1	2.5-3.0	550-560	400-500	364	700	40	45	3W
GM-35E42P630KN-S1	2.0-2.4	620-640	700-800	614	1000	15	45	3W
GM-35E55N660KN-S1	2.0-2.4	650-665	1400-1600	2134	1000	17	45	3W

---

ir led 1w ir 3535 3w smd leds 850nm 940nm specifications:

ir led 1w ir 3535 3w smd leds 850nm 940nm application

Security monitoring

About Guangmai LED/ GMKJ LED

Shenzhen Guangmai Technology Co., Ltd. Is a professional LED package manufacturer integrating R & D,production,sales and service.The company's development strategy is "brand, technology, innovation, leading" .Adhering to the "quality first, service first" business philosophy.Advocate "energy conservation and environment protection, green lighting"，Guided by emerging LED lighting market，Products are exported to North America, Europe, Australia, Japan developed country etc.

Main products:LED beads include UVC deep UV lamp beads,UVA purple lamp beads,IR lamp beads,Led plant red light,SMD double color temperature lamp beads,SMD molding lamp bead,LED high voltage lamp beads,LED high power lamp beads,Cob surface light source,LED integrated light source etc.The finished lighting include Floor lamp, night lamp, table lamp ,Selfie light etc.

Our company based on "people-oriented, Survive by quality, Market-oriented "purpose,Sincerely hope to cooperate with friends around the world,We establish cooperative relations under the principles of fairness,honesty and mutual benefit,Common development, welcome customers from all over the world to contact us to business negotiations.

Delivery:

FAQ:

1.  Q:Could I place the sample order for further checking before mass production?

A:Absolutely and welcome to take the samples for testing first.



2.  Q:How long is the order lead time?

A:The sample could be finished within 7 days,and normally the mass production could be finished within 15days,it depends on the quantity as well.



3. Q:How is the warranty?

A:Our company offers 3-year warranty for all products.



4. Q:How do you ship the goods to us?

A:Usually,We would ship the goods via Express like UPS/DHL/Fedex etc,and it would take around 5－7 days.With large quantity,we suggest to send them by sea,and it would take around 15-20 days.

---

Datasheet:

For more details, please feel free to contact with Guangmai Tech directly.

You can download the English Version datasheet of ir led 1w ir 3535 3w smd leds 850nm 940nm from the head of this page.
