UV LED 365nm 370nm 385nm 395nm 405nm UVA LED Chip For UV Curing Machine

Production Introduction

Item	UV LED 365nm 370nm 385nm 395nm 405nm UVA LED Chip for UV Curing Machine
Type	UV LED 365nm/ UVA LED
Power	1W 3W
Input Voltage	DC 3.6-4.0V
Forward Current	350mA 700mA
Viewing Angle	60/120 degrees
Wavelength	UV LED 365nm 370nm 380nm 385nm 390nm 395nm 405nm
Application	1. UV Curing 2. Printing 3. Coating 4. Adhesive 5. Counterfeit Detection/Security 6. UV Torch 7. Fluorescence Photography 8. Dental Curing 9. Crime Inspection 10. Oil Leak Detection

Features

LED UV VS Traditional UV

1. In millimeters, it is convenient for product structure design and reduce the volume of application products.

2. The wavelength is concentrated, the light use efficiency is extremely high, and the wavelength width is very narrow.

3. No pollutants in production and use.

4. The rated power is less than 1w, very energy saving.

5. It is not easy to be damaged during use, and the transportation is safer.

6. Instant start, no ballast and starter

Application

1. UV Curing

2. Printing

3. Coating

4. Adhesive

5. Counterfeit Detection/Security

6. UV Torch

7. Fluorescence Photography

8. Dental Curing

9. Crime Inspection

10. Oil Leak Detection

Why Us

1. Focus on the industry

2. Strength factory

3. Certificated

4. 50-100 Skilled staffs

5. OEM Customized

6. Professional service

Company Profile

Shenzhen Guangmai Technology Co., Ltd. was established in 2009 with a registered capital of 30 million yuan.



It is a high-tech company specializing in the production and sales of LED product packaging integrating R&D, production, sales and service.



The main business of Guangmai Technology is 2835, 5730, 3030, 3535, 5050, 3528, 3014, 1-3W high-power led, 3 -100W COB LED, UV and IR.



We have established long-term and stable cooperative relations with internationally renowned chip manufacturers such as Bridgelux, Epileds, Epistar and Sanan, etc.

Related Knowledge

UVA wavelength 320-400nm

1. UVA conforms to the phototaxis response curve of insects, and can be used to make insect trapping lamps and mosquito killer lamps.



2. UVA is the central area of plant phototaxis, and can stimulate cyanine pigments, which can be used in plant lights.



3. The fluorescent agent can be identified under UVA irradiation and make it glow, which is widely used in gemstone identification.



4. When UVA is irradiated on the scorpion shell, it will fluoresce, which can be used to make scorpion trapping lights.



5. UVA can excite the photocatalyst and produce strong oxidizing substances, which play the role of sterilization and deodorization.



6. Beige and beige fabrics under UVA irradiation can be clearly identified and can be used for fabric color identification.



7. The specific wavelength in UVA can be absorbed by the photoinitiator in the UV glue, resulting in a chemical reaction, which promotes the formation and curing of the UV glue in a few seconds, and can be used for UV curing lamps and nail lamps.
