3535 Ceramic 10W Round White LED for High-Intensity Spotlights and Long-Throw Lighting
| Parameter | Specification |
| Part Number | GDY-3535WXXX-1CC-S1E5YBP-R70 |
| LED Power | 10W |
| LED Type | Round high power LED |
| CCT(k) | 3000k/4000k/5000k/6000k/7000k |
| CRI | 70/80/90 |
| Foward Voltage | 3.2-3.8V |
| Drive Current(mA) | Max up to 3000mA |
| Luminous Flux(lm) | 1000-1200lm at 3000mA |
| Emitting Area(mm) | 1.3mm |
| Package Material | Ceramic Substrate |
| Forward Voltage (Vf) | 3V |
| Application | Professional Spotlights & Searchlights/Stadium & High-Bay Lighting |
Round LED vs. Standard 3535 LED
| Feature | Standard 3535 LED 10W | GMKJ 3535 Round LED 10W |
| Part Number | GDY-3535W600-1CD0-J2G7DM-R70 | GDY-5050W600-1CC-S1E5YBP-R70 |
| Image |
|
|
| Emitter Shape | Conventional rectangular/square emitting area | Compact round emitting surface |
| Optical Coupling | General-purpose optical design; extra effort to round the spot | Perfect match with secondary optics, delivers clean circular beam spot |
| Long-Throw Lighting | Performance heavily relies on external lens design | Pre-optimized for directional & long-distance illumination, less stray light |
| Beam Angle | 120 with dome | Flat 120 |
| Optical System | Fits conventional standard fixtures | Optimized for compact optical assemblies |
| Best Use Cases | General lighting, panel lights, linear fixtures | Spotlights, searchlights, directional long-range lighting |
Compact 3535 Round Emitter Design
15W 9V 3535 Ceramic SMD High Power White LED Electrical Parameters
|
Parameter |
Symbol |
Conditions |
Min |
Avg. |
Max |
Units |
| Forward Voltage (Vf) |
VF |
IF=3000mA |
3.20 |
-- |
3.80 |
V |
|
Thermal Resistance Junction To Board (热阻) |
RΘJ-B |
IF=3000mA |
-- |
2 |
-- |
°C/W |
|
Luminous Flux (流明) |
Φe |
IF=3-00mA |
1000 |
-- |
1200 |
LM |
|
GDY-3535W300-1CC0-SA55YBP-R70
|
λp |
IF=3000mA |
2800 |
-- |
3200 |
K |
|
GDY-3535W400-1CC0-SA55YBP-R70
|
λp |
IF=3000mA |
3700 |
-- |
4300 |
K |
|
GDY-3535W500-1CC0-SA55YBP-R70
|
λp |
IF=3000mA |
4700 |
-- |
5300 |
K |
|
GDY-3535W650-1CC0-SA55YBP-R70
|
λp |
IF=3000mA |
6200 |
-- |
6800 |
K |
|
CRI
(显色指数)
|
Ra
|
IF=3000mA | -- | 70 | -- | |
|
Reverse Current (反向漏电流) |
IR |
VR=5V |
−− |
−− |
10 |
μ A |
|
Viewing Angle [1] (发光角度) |
2Θ1/2 |
IF=3000mA |
−− |
120 |
−− |
Deg |
Need a High-Intensity Round LED for Your Lighting Project?
GMKJ provides 3535 ceramic Round LED solutions for applications requiring high luminous intensity, controlled beam performance and long-distance illumination.
Contact our engineering team for technical specifications, optical recommendations or evaluation samples.
Technical Support Available
White LED Specification Selection
Color Temperature Customization
LED Module Design
PCB Layout Support
Thermal Performance Optimization
Sample Testing Support
