Production Introduction
| Name | High brightness 3535 ceramic white smd led chip cool white 6500k |
| Power | 1-3w |
| Current | 700mA |
| Voltage | 2.8-3.4vdc |
| CCT | 6000-6500k |
| CRI | 70 |
| Life-span | 50000 hours |
| Chip brand | Bridgelux 45mil |
| Warranty | 3 years |
| Usage | spotlight, ceiling light, down light, wall lamp, garden light, lighting projecters and so on |
Product parameters
Features
• Well-known chip material, Bridgelux
• 99.99% gold wire bonding
• High flux per LED
• Industry best moisture sensitivity
• Low-temp & lead-free reflow soldering
• More energy efficient than incandescent and most halogen lamps
• Low Voltage DC operated
• Instant light(less than 100ns)
• RoHS, CE compliant
About 3535 ceramic led
About 3535 ceramic led
3535 refers to the appearance of the lamp bead package size 3.5 MM (length) * 3.5 MM (wide) ceramic lamp bead is a new type of 3535 a lamp bead, unlike imitation lumens appearance size and encapsulation technology, ceramic 3535 appearance size is 3.5 * 3.5 * 2.2 MM, the volume is much smaller than imitation lumens high-power, even smaller than conventional lamp bead volume 5050, although it is small in size but power and lumen is the same can do 1-3 w, photosynthetic efficiency is higher than the imitation lumens, both the light Angle is the same is 120 °.
3535 points of ceramic material and PPA material, different material 3535 lamp bead maximum power is not the same, such as the 3535 largest PPA material can only be 0.5 W, and ceramic 3535 lamp bead is usually 1-3 W, 5 W, big can of course get the main emitting light colors are red, yellow, purple, blue, RGB, RGBW full color, monochrome and color mixing is widely used in industrial and mining lamp, street lamp, stage lights and other lighting areas and plant lighting, is an excellent material to replace imitation lumens structure of high power.
Applications
• Portable (flashlight, bicycle)
• Uplighters/Downlighters
• Decorative/Entertainment (stage light)
• Bollards/Security/Garden
• Indoor/Outdoor Commercial and Residential Architectural
• Automotive Ext (Stop-Tail-Turn, CHMSL, Width Lamp)
Why choose us
1. 3 years warranty
2. 13 years technical service team
3. We are Alibaba Assessed 13 years Gold Supplier
4. Professional sales team
5. Free Sample is available
6. Fast delivery
7. 100% QC inspection Before Shippment
8. Support customization, welcome to contact us
Shippment
FAQ
1. What will be the best price terms?
We can accept FOB, EXW, CIF normally and other terms according to customers special requirement.
2. How long does it take to customize a sample?
We have large quantities in Stock for normal color,Normal size ,for special color and products sizes it need to 5-7 days to customize.
3. Could you please send me the sample for checking? So that I could see and analyze its quality?
Yes. We can send samples first, samples need to be charged if the value is too high.
4. How soon will my order shipped?
Generally, upon the receipt of payment, goods will be shipped out within 2 working days for samples. (Note: Exact delivery time mainly depends on the carrier services.)
5. How much will the express delivery cost?
The shipping discount are different because of different weight, volume and destination. We will choose the cheapest and safest way according to your detailed requirement. For the exact cost, please contact us freely.
6. How to choose LED chips?
Lumens(LM), light efficency(LM/W), life span((hrs) are very important factors when choosing LED light source. The higher, the better. Besides, brand of LED chip, LED base and other materials will influence the product reliability.
7. What's your Delivery Time?
We need 8-12 days to prepare the goods and then we will ship out ASAP.
8. How do I track my shipment?
We will send email with tracking number, so you can check the progress of your delivery online.
