Products Description
6VDC 12VDC 40W high power 7070 SMD LED diode Specs:
| Product name | 6VDC 12VDC 40W high power 7070 SMD LED diode |
| Part number | GD-7070W600-4CD0-SL77M |
| Chips brand | China Shilan 77mil chip*4 chips inside, 4S1P |
| Input |
With diffrent pad design, it will have different voltage input: 12vdc with max 3000mA; or 6vdc with max 6000mA; |
| Flux | 3800-4000lm at 12vdc 3000mA input or 6vdc 6000mA input |
| Lighting Efficiency | Around 120-140lm per watt at 40 Watt full power loaded |
| Color |
2700K, 3000K, 4000K 5000K, 5700K and 6500K optional CRI: Ra>70 for outdoor lights CRI: Ra>80 for indoor lights |
| Power |
Max 40 Watt power loaded |
| Ceramic package material |
Ceramic package; Both dome silicone lens and flat package 7070 smd leds are available. |
| Lighting angle |
120 degree dome silicone lens or 120 degree flat package without lens |
| Brand and manufacturer | GMLEDs, GMKJ |
| Warranty | 3 years |
| OEM service |
1. SKD parts available; 2. Aluminum pcb boards LED assembly service is also available here. |
6VDC 12VDC 40W high power 7070 SMD LED diode picture:
| Dome silicone lens 7070 smd leds | Flat packge 7070 smd leds without dome silicone lens |
 |
 |
6VDC 12VDC 40W high power 7070 SMD LED diode pad design description:
Different PCB board pad design will have different input voltage requirement for the LEDs.
| 7070 smd led pcb board design for 12vdc | 7070 smd led pcb board design for 6vdc |
 |
 |
6VDC 12VDC 40W high power 7070 SMD LED diode dimensions:
12VDC 40W high power 7070 SMD LED diode Eletrical specs:
|
Parameter |
Symbol |
Conditions |
Min |
Avg. |
Max |
Units |
|
Forward Voltage |
VF |
IF=3000mA |
11.0 |
-- |
13.0 |
V |
|
Thermal Resistance Junction To Board |
RΘJ-B |
IF=3000mA |
-- |
1 |
-- |
°C/W |
|
Luminous Flux |
Φv |
IF=3000mA |
3800 |
-- |
4000 |
lm |
|
Color Temperature |
CCT |
IF=3000mA |
6000 |
-- |
7000 |
K |
|
CRI |
Ra |
IF=3000mA |
70 |
-- |
-- |
-- |
|
Reverse Current |
IR |
VR=20V |
−− |
−− |
10 |
μ A |
|
Viewing Angle |
2Θ1/2 |
IF=3000mA |
−− |
120 |
−− |
Deg |
6VDC 40W high power 7070 SMD LED diode Eletrical specs:
|
Parameter |
Symbol |
Conditions |
Min |
Avg. |
Max |
Units |
|
Forward Voltage |
VF |
IF=6000mA |
6.00 |
-- |
8.00 |
V |
|
Thermal Resistance Junction To Board |
RΘJ-B |
IF=6000mA |
-- |
1 |
-- |
°C/W |
|
Luminous Flux |
Φv |
IF=6000mA |
3800 |
4000 |
lm |
|
|
Color Temperature |
CCT |
IF=6000mA |
6000 |
7000 |
K |
|
|
CRI |
Ra |
IF=6000mA |
70 |
-- |
-- |
-- |
|
Temperature Coefficient of Forward Voltage |
∆VF/∆T |
IF=6000mA |
−− |
-2 |
−− |
mV/°C |
|
Reverse Current |
IR |
VR=20V |
−− |
−− |
10 |
μ A |
|
Viewing Angle |
2Θ1/2 |
IF=6000mA |
−− |
120 |
−− |
Deg |
Application
6VDC 12VDC 40W high power 7070 SMD LED diode applications
6VDC 12VDC 40W high power 7070 SMD LED diode is mainly used for Automotive lighting, UFO lights, LED flash light, stadium lights and other applications.
